This is the ring polish machine, a device that polishes the guide ring and inner ring; especially for the polishing of the welded guide ring and inner ring with the ring polish machine, the machining range is 6 inches and above; the ring forming machine complements it in the ring processing line, with workpiece thickness of 2mm-5mm and width of 5mm-50mm; the operation is simple, and the operator only needs to feed and unload; the polishing wheel is a conventional consumable, which is easy to buy and replace.
| Type | MRP-14 |
| Machine profile | 1100*1600*1200mm |
| Net weight | 230KG |
| Power supply | 2KW |
| Voltage | 380V |
| Work range | 6" and above |
| Thickness | 2-5 mm |
| Flange width | 5-50 mm |
| Cycle time | <20s |
| Material suited | CS/SS |
| Dust collection | Yes |
| Ring loading | Manual |
